MJE13009 Transistor

  Type Designator: MJE13009
   Material of Transistor: Si
   Polarity: NPN
   Maximum Collector Power Dissipation (Pc): 100 W
   Maximum Collector-Base Voltage |Vcb|: 700 V
   Maximum Collector-Emitter Voltage |Vce|: 400 V
   Maximum Emitter-Base Voltage |Veb|: 9 V
   Maximum Collector Current |Ic max|: 12 A
   Max. Operating Junction Temperature (Tj): 150 °C
   Collector Capacitance (Cc): 160 pF
   Forward Current Transfer Ratio (hFE), MIN: 8
